Galvanized Wire Mesh Specifications Materials Types and Industrial Applications

Galvanized wire mesh consists of steel wire coated with zinc. The zinc coating provides corrosion resistance and rust prevention. Manufacturing methods include electro-galvanizing and hot-dip galvanizing, applied before or after weaving or welding. Applications include fencing, agricultural enclosures, concrete reinforcement, security screens, and filtration. Galvanized wire mesh delivers structural strength and longevity in indoor and outdoor environments.

Specifications

• Material: Low carbon steel wire, galvanized steel wire, galvanized iron wire.
• Process: Hot-dip galvanizing, electro galvanizing, pre-galvanized wire, and post-galvanized mesh.
• Weaving: Plain weave
• Mesh: 1–635 mesh per inch.
• Wire Diameter: Including 0.5 mm, 1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm, and 4.0 mm.
• Aperture Size: Including 1 mm, 5 mm, 10 mm, 25 mm, 50 mm, and 100 mm.
• Zinc Coating Weight: Electro galvanized: 10–30 g/m2; hot-dip galvanized: 40–300 g/m2.
• Roll Width: 0.5–2.5 m, with customized widths available.
• Roll Length: 10 m, 25 m, 30 m, 50 m, 100 m, and custom lengths.
• Product Forms: Wire mesh rolls, sheets, panels, fence panels, baskets, cages, filters, and fabricated parts.
• Surface Treatment: Galvanized coating, PVC coating, and custom surface processing.
• Edge Processing: Cut edges, folded edges, reinforced edges, and framed edges.
• Filtration Range: Used for particle screening, material separation, and industrial filtration.
• Customization: Custom mesh count, wire diameter, coating weight, dimensions, and processing methods.
• Packaging: Roll packaging, pallet packaging, wooden case packaging, and customized packing.
• Roll Core: Paper core, plastic core, steel core, and customized core types.

Features

• Galvanized Wire Mesh features corrosion resistance, zinc coating, wire strength, uniform openings, and processing options.

Applications

• Construction: Used for reinforcement, protection, and building projects.
• Agriculture: Used for animal fencing, cages, and farm applications.
• Fencing: Used for security fences, barriers, and enclosures.
• Filtration: Used for screening, particle separation, and industrial filtration.
• Mining: Used for material screening and separation systems.
• Industrial Equipment: Used for protective covers and machine components.
